Views: 0 Author: Site Editor Publish Time: 2025-09-07 Origin: Site
On August 21st, 2025, Xinjiang Institute of Physical and Chemical Technology, Chinese Academy of Sciences (hereinafter referred to as "Xinjiang Institute of Physical and Chemical Technology") ushered in a key and exciting moment of upgrading scientific research equipment-an advanced evaporation coating machine PD-300 delivered by Pudi vacuum to Xinjiang Institute of Physical and Chemical Technology officially completed the delivery and acceptance.
Brief introduction of delivery equipment
Evaporative coating machine PD-300
Vacuum limit and pumping speed:
It is better than 5.0×10^-5Pa atmospheric pumping and 8× 10-4pa ≤ 30min.
Substrate table:
The substrate table is less than or equal to ≤100mm×100mm, and the source-base distance is greater than 300mm.
Evaporation source and power supply:
There are 2 groups of independent water-cooled electrode evaporation sources, and the constant voltage and constant current mode of 2kw evaporation power supply is optional.
application area:
Research on preparation of metal electrode layer and new energy materials in laboratories of scientific research institutes in colleges and universities.
Delivery site direct hit
At the acceptance site, the researchers of Xinjiang Institute of Physics and Chemistry and the after-sales engineer of Pudi Vacuum witnessed this important moment together.
During the acceptance process, Pudi after-sales engineers conducted a comprehensive inspection and evaluation of various performance indicators of PD-300 in strict accordance with predetermined standards and processes. They carefully checked the key links such as the operation stability, coating quality and control system of the equipment to ensure that the equipment can be put into normal use.
After rigorous testing and verification, all the performance indexes of PD-300 have reached the expected requirements and successfully passed the delivery acceptance.
